(1) Omega-holders
(2) Clamp
(3) Safety-rope
(4) Quick-lock fastener

DMX512 control

The wires must not come into contact with each other, otherwise
Please note, the starting address depends upon which controller is being used.
Device 3
Starting address 23
DMX IN DMX OUT
1: Ground
POWER IN
2: Signal (–)
100-240 V AC, 50/60 Hz
3: Signal (+)
120 Ohms
Only use a DMX cable and 3-pin XLR plugs and connectors in order to connect the controller with the fixture
or one fixture with another.

Occupation of the XLR connection:

the devices will not work at all, or will not work properly.
Starting address 12
DMX IN DMX OUT
ON
FUSE:
OFF
T2A/250V
1: Ground
2: Signal (–)
3: Signal (+)
1
Device 2
ON
FUSE:
OFF
T2A/250V
POWER IN
100-240 V AC, 50/60 Hz
30/44
3
2
4
Device 1
Starting address 1
DMX IN DMX OUT
1: Ground
POWER IN
2: Signal (–)
100-240 V AC, 50/60 Hz
3: Signal (+)
DMX-512 Controller
00103748.DOC, Version 1.0
ON
FUSE:
OFF
T2A/250V
