DESCRIPTION OF THE DEVICE

Features

LED beam pyramid with unlimited PAN movement
Equipped with nine 8 W quadcolor LEDs with RGBW colors
•
DMX-controlled operation or stand-alone operation with Master/Slave function
•
DMX512 control possible via any commercial DMX controller (occupies max. 49 channels)
•
5, 8, 11, 13, 22 or 49 DMX channels selectable
•
Positioning within 540° PAN
•
Exact positioning via 16 bit PAN movement resolution
•
With Infinity function for unlimited PAN movement
•
PAN-angle adjustable
•
Each LED can be controlled individually
•
Sound-controlled via built-in microphone
•
Microphone sensitivity adjustable via control board
•
Fan-cooled
•
Narrow illumination angle
•
• Addressing and setting via control board with LCD
Functions: colored RGBW beams, stepless RGBW color changing, color presets for each LED
•
independently controllable, internal programs, dimmer, strobe effect with variable speed, sound
control, Master/Slave operation
Flicker-free projection
•
Standing or hanging installation possible
•
Switch-mode power supply for operation between 100 and 240 volts
•
Ready for connection via P-Con power cord with safety plug
•

Overview

3
1
(1) Lenses with 8 W LEDs
2
(2) Base with carrying handles
(3) Control Board with operating
buttons
