InSTAllATIon InSTRuCTIonS
foR DIRECTTECH CRYSTAl & DIRECTTECH mIRRoR wITH STAnDS
Delivery contents:
• 1 piece DIRECTTECH heating panel (optionally connecting
cable with Schuko plug)
• 2 pieces of stands
• 4 pieces covering caps
Additional accessories:
(not included in delivery)
• hexagonal key
• in accordance with local conditions
appropriate mounting material
(with 2 persons)
Top
Glass
SKETCH
205 mm 225 mm
Installation:
1. Lay down the DIRECTTECH heating panel carefully with the glass
side on a horizontal surface (use the paperboard as supporting
underlay).
2. Screw the supplied stands (feet) with the hexagon screws
M8x30mm into the square nuts (4 pieces) on the backside of the
profi le. Please ensure that the longer part of the stands is at the
back (picture).
3. Stick the supplied covering caps over the heads of the hexagon
screws.
4. Please ensure that the part of the panel declared with "top" points
upwards (see Manual p. 7 / sketch wall installation) to guarantee
that the DIRECTTECH heating panel works properly.
Dismantling:
1. Pull out the mains plug from the socket.
2. The dismantling takes place in reverse sequence.
63
