InSTAllATIon InSTRuCTIonS

foR DIRECTTECH CRYSTAl & DIRECTTECH mIRRoR
Delivery contents:
•
1 piece DIRECTTECH heating panel
•
2 pieces clip brackets, attached on heating panel
Additional accessories:
(not included in delivery)
•
in accordance with local conditions appropriate mounting material
SKETCH
Drilling holes
Clip brackets
for mounting
screws
The installation site must provide a suffi cient carrying capacity and strength in accordance
with the weight of the product. Please hereto consult your ceiling installer/architect.
(wITH 2 pERSonS)
Installation:
1. Fasten the clip brackets, in parallel position, with the appropriate
2. For electric installations, the regulations of EN/VDE and of the local
3. Now push the DIRECTTECH heating panel with the frame profi le
4. Before you release the DIRECTTECH heating panel, please make sure
Dismantling:
1. Disconnect the electrical connections according to safety instructions
2. Push the DIRECTTECH heating panel in one direction against the
Clips
3. Place the DIRECTTECH heating panel carefully on its backside to avoid
4. By installing as well as dismantling of the DIRECTTECH heating panel,
46
with clip bracket basic
fastening material for the mounting surface. The distance of the
clip brackets should at least have half the length of the DIRECTTECH
heating panel. Attention! Do not install the brackets in a bended or
compressed state (see p.47).
power supply company (EVU) are decisive.
placed on the backside acc. to the drawing (see p.47) against the clips
at the end of the clip bracket. Please push the panel softly against the
clips until you can hear it snaping (click), when the clips snap in the
profi le path.
that the clips had indeed locked into place.
and technical rules.
clip brackets until the clip releases at the end of the clip bracket (it
unclips). Then take the DIRECTTECH heating panel on the released
side to the front and subsequently you can release the opposite side
by lifting up the clip of the clip brackets from the frame profi le on the
backside.
damages of the carrier material (glass or mirror).
the clips may be bent through excessively heavy pressing. Therefore,
it is important to ensure that the condition of the clips is proper
before you start the re-installation (see p.47).
