for type Eu 1: 1150 x 600 mm
SKETCH
The installation site must provide a suffi cient carrying capacity and strength in accordance
with the weight of the product. Please hereto consult your ceiling installer/architect.
Back side view
1150 mm
A: 850 mm
B: 300 mm
18 mm
18 mm
36 mm
60 mm
59
Side view
Nut 1
Nut 2
Hight-adjusting screw
Spacer
sleeves
Wall bracket
2 holes each 6,5 mm
Clasp (agraffe)
Wall
