InSTAllATIon InSTRuCTIonS
foR DIRECTTECH HEATInG pAnElS In A SuSpEnDED CEIlInG

Delivery contents:

(500er/1000er/1300er/2000er)
• 1 piece DIRECTTECH heating panel
• 4/6 pieces Z-profiles
• 4/6 pieces Allen screws (cylinder head screws) M8*10
• 4/6 pieces square nuts

Additional accessories:

(not included in delivery)
• 1 piece Allen key 6 mm
!
Before installing the DIRECTTECH heating panels,
an ultimate load testing of the suspended ceiling
has to be carried out! For the carrying capacity of
the existing suspended ceiling, we do not assume
any warranty and liability.
Weight indication of the DIRECTTECH heating
panels:
IP2000 / IP1300 / D1000 CRYSTAL
IP2000 / IP1300 / D1000 MIRROR
D500 CRYSTAL
D500 MIRROR
The installation site must provide a sufficient carrying capacity and strength in accordance
with the weight of the product. Please hereto consult your ceiling installer/architect.
Installation:
1. Use the Allen key to tighten the Z-profiles with the Allen screws
2. Regarding D1000 DIRECTTECH heating panels, two Z-profiles with
3. The electrical connections must be made according to the safety
4. After fastening the Z-profiles you can now hook in the
Dismantling:
1. Disconnect the electrical connections according to the safety
2. Lift the DIRECTTECH heating panel out of the suspended ceiling.
12 kg
15 kg
6 kg
8 kg
56
M8*10 and the square nuts.
a distance of 52 mm are mounted to the exterior edge on each
long side and one in the middle. Regarding D500 DIRECTTECH
heating panels, two Z-profiles with a distance of 52 mm are
mounted on two sides to the exterior edge and one in the middle.
Double-check the firm and secure position of the bracket!
instructions and the technical rules. For electric installation works,
the regulations of EN/VDE and of the local power supply company
(EVU) are decisive.
DIRECTTECH heating panel into the suspended ceiling.
instructions and technical rules.
