Electrical connection of evaporator: connect the evaporator. Close the connection box and fix the cable so that
it does not interfere with fan operation.
Close evaporator cover by repeating operations A) in reverse order.
LBCWH
Install the evaporator as follows:
B) open fan cover A by unscrewing the 2 screws B; drill the holes in the ceiling keeping the necessary
distance from the wall.
Secure the evaporator with the material supplied.
Mod. D
030-050 508
060-075 928
