► This ASCII code could be:
1 - The time information using the protocol described in the above table
generated by an RT4000 or any other ASCII code generator.
2 - Or the information from another clock of the same type functioning in trans-
mitter mode, in which case the clock is completely enslaved to the latter.
3 - In HORO QUARTZ specific version the time information from a HORO
QUARTZ pointing system.
B. Polaris Protocol
► The time information received must be in the following form:
Here is the detailed description of the frame:
Byte Nr Field
1 \
2 H
3 m
4 S
5 C
6 Y
7 M
8 D
9 W
10, 11 0, 0
12 CHK
MDE-HANDI-2078V2.2
\ H M S C Y M D W 0 0 CHK
Size Value/Meaning
1 Back slash character ($5C)
1 Hours on one binary character ($00 to $17)
1 Minutes on one binary character ($00 to $3B)
1 Seconds on one binary character ($00 to $3B)
1 Century on one binary character ($00 to $63)
1 Year in the century on one binary character ($00 to $63)
1 Month in the year on one binary character ($01to $0C)
1 Day in the month on one binary character ($01-$1F)
Weekday on one binary character ($01 to $07 for Monday to
1
Sunday)
2 Null character ($00)
1 Checksum = Sum in hexadecimal of all Field excluding the first
