see sketch
Ref No. Parts No.
1 T6156A-01
2 T6156A-02
3 T6156A-03
4 T6156A-04
5 T6156A-05
6 T6156A-06
7 T6156A-07
8 T6156A-08
9 T6156A-09
10 T6156A-10
11 T6156A-11
12 T6156A-12
13 T6156A-13
14 T6156A-14
15 T6156A-15
16 T6156A-16
17 T6156A-17
18 T6156A-18
19 T6156A-19
20 T6156A-20
21 T6156A-21
22 T6156A-22
23 T6156A-23
24 T6156A-24
25 T6156A-25
26 T6156A-26
27 T6156A-27
28 T6156A-28
29 T6156A-29
30 T6156A-30
31 T6156A-31
32 T6156A-32
33 T6156A-33
34 T6156A-34
35 T6156A-35
36 T6156A-36
37 T6156A-37
38 T6156A-38
39 T6156A-39
40 T6156A-40
41 T6156A-41
42 T6156A-42
43 T6156A-43
44 T6156A-44
45 T6156A-45
46 T6156A-46
47 T6156A-47
48 T6156A-48
49 T6156A-49
50 T6156A-50
51 T6156A-51
52 T6156A-52
53 T6156A-53
54 T6156A-54
55 T6156A-55
56 T6156A-56
57 T6156A-57
58 T6156A-58
59 T6156A-59
60 T6156A-60
61 T6156A-61
62 T6156A-62
63 T6156A-63
64 T6156A-64
65 T6156A-65
66 T6156A-66
67 T6156A-67
68 T6156A-68
69 T6156A-69
*in order to attain a maximum service life and performance of the compressed air it is recommended to replace whole
subassemblies.
Description
HOUSING
"O" RING
PUSHER
PLUG
VALVE SPRING
VALVE STEM
"O" RING
"O" RING
VALVE BUSHING
"O" RING
PIN
"O" RING
MUFFLER BODY
SILENCER
FILTER SCREEN
PLATE
RETAINER RING (R-15)
SET SCREW
AIR INLET
HEX. SCREW (M3×12L)
BALL BEARING (696 ZZ)
"O" RING (d31.5×W2.4)
REAR END PLATE
SPRING PIN (Ø2.5×5L)
ROTOR BLADE
ROTOR
CYLINDER
BALL BEARING (6900ZZ)
INTERNAL GEAR (16mm)
GEAR (13T)
PIN (Ø3×10.8L)
DRIVEING GEAR
WASHER
BALL BEARING (R8)
INTERNAL GEAR (15mm)
GEAR (14T)
PIN (Ø3×13.8L)
GEAR CASE
WASHER
BALL BEARING (R6 ZZ)
GEAR CASE
STEEL BALL (Ø4mm)
SPRING
GEAR HOUSING
SPRING
BIT HOLDER
SET SCREW (M5×5L)
DRILL BIT 8mm
CLAMP NUT
"O" RING (d39.35×W2.62)
"O" RING (d32.0×W1.5)
RETAINING RING
LOCK NUT
ADJUSTING NUT
SET SCREW (M4×6L)
WAVE WASHER
RETAINING RING (S-22)
ATTACHMENT
SPRING
RETAINER
SUPPORTER
HEX. SCREW (M4×8L)
ARM 2"
HEX. WRENCH (2.5mm)
SPRING PIN
TRIGGER
SPRING
SCREW
SPRING PIN
Q'TY
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
5
1
1
1
1
2
2
1
1
2
1
2
2
1
1
1
1
3
1
1
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
