All rights reserved. Subject to change without notice.
This document applies for the deTec4 Prime safety light curtain.
DANGER
Hazard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
Please observe the safety notes provided.
b
The safety light curtain is not suitable for the following applications, among others:
• Outdoors
• Underwater
•
In explosion-hazardous areas
•
At altitudes over 3,000 m above sea level
•
In environments with enhanced ionizing radiation
A fuse rated maximum 2 A shall be installed in the isolated 24 V DC power supply cir‐
cuit to the device in order to limit the available current.
For more information about how to work with the protective device, refer to the machi‐
nery documentation or the operating instructions for the protective device. You can call
up the EU declaration of conformity and the current operating instructions for the pro‐
tective device by entering the part number in the search field at
number: see the type label entry in the "Ident. no." field).
The symbol indicates the sender.
s
The symbol indicates the receiver.
r
Complete overview of the LED statuses and their meanings: see operating instructions.
Sender indicators
Position of light emitting diodes:
Receiver indicators
Position of light emitting diodes:
The blue alignment quality light emitting diodes in combination with the red flashing
ERR LED also denote faults.
System plug:v C
MOUNTING INSTRUCTIONS
A
B
M O U N T I N G I N S T R U C T I O N S | deTec4 Prime
www.sick.com (part
11
