EX-41016-2

1. Description

The EX-41016-2 is a plug & play high-speed serial RS-232 expansion card for the PCI
Bus. The EX-41016-2 provides sixteen 9 pin high speed RS-232 serial ports. It uses
data transfer rates up to 921Kbaud/s. The EX-41016-2 design utilizes the SystemBase
chipset with 256-byte buffer, which incorporates the latest in high speed interface tech-
nology. In combination with the fast PCI bus it provides a secure and very high data
transfer on each port. It supports 32-bit PCI & PCI-X bus with 5 Volt and 3,3 Volt. It is
not possible to change the address or IRQ settings manually, they will be obtained au-
tomatically by the system BIOS and operating system. With the jumpers you can enable
power to pin 9. Please note if you use power to pin 9 your peripheral device must sup-
port it. Furthermore, you can use another jumper to set the voltage of +5V or +3,3V on
the UART. There is additionally a 8 cm low profile slot bracket for installation in small
computer housing.
Features:
•
Compatible for PCI and PCI-X bus
•
Up to 921.6 Kbps Baud Rate
•
Support RS-232
•
Support Windows NT 4.0/ 9x/ 2000/ XP/ Vista/ 7/ 8.x/ 10/ Server 20xx/ Linux
•
Certificate for CE / FCC / RoHS / WEEE

2. Extent of Delivery

Before you install the EX-41016-2 in your PC, please check at first the contents of the
delivery:
•
EX-41016-2
•
Driver CD
•
Manual
•
2x Octopus Cable
•
Low Profile Bracket
