Exsys EX-41088 Anleitung

CONNECTORS
DB62F:
62 Pin Serial RS-232 Female Connector
Pin Signal Pin
1 TXD 1 22
2 DTR 1 23
3 RXD 2 24
4 DSR 2 25
5 DCD 2 26
6 TXD 3 27
7 DTR 3 28
8 RXD 4 29
9 DSR 4 30
10 DCD 4 31
11 RXD 5 32
12 DSR 5 33
13 DCD 5 34
14 TXD 6 35
15 DTR 6 36
16 RXD 7 37
17 DSR 7 38
18 DCD 7 39
19 RXD 8 40
20 DSR 8 41
21 DCD 8 42
HARDWARE INSTALLATION
If you are ready with the jumper settings, please proceed with the following installation instructions.
Because there are large differences between PC's, we can give you only a general installation
guide. Please refer to your computer's reference manual whenever in doubt.
1. Turn off the power to your computer and any other connected peripherals.
2. Remove the mounting screws located at the rear and/ or sides panels of your Computer and
gently slide the cover off.
3. Locate an available PCI expansion slot and remove its covers from the rear panel of your
computer. Make sure it is the right PCI expansion slot for the card (see card description)
4. Align the card with the expansion slot, and then gently but firmly, insert the card. Make sure
the card is seated and oriented correctly. Never insert the card by force!
5. Then connect the card with a screw to the rear panel of the computer case.
6. Gently replace your computer's cover and the mounting screws.
5
DRIVER INSTALLATION
Windows
After the hardware installation Windows will recognize the card automatically and install the
drivers. If the driver should not be installed automatically, please insert the Driver CD into your
CD-Rom drive (e.g. Drive D:) and open the folder „USB_to_IO/FTDI". Please select the folder
Signal Pin Signal
with your operating system and install the driver (see Picture). Follow the hardware assistant
RXD 1 43 CTS 1
and finish the installation. Important! Restart your PC in any case after installing the drivers.
DSR 1 44 RTS 1
DCD 1 45 GND
TXD 2 46 CTS 2
DTR 2 47 RTS 2
RXD 3 48 CTS 3
DSR 3 49 RTS 3
DCD 3 50 GND
TXD 4 51 CTS 4
DTR 4 52 RTS 4
GND 53 CTS 5
CHECK INSTALLED DRIVER
TXD 5 54 RTS 5
Open the >Device manager<. Now you should see at „Ports (COM & LPT)" and „USB-
DTR 5 55 GND Controller" the following new entry's:
RXD 6 56 CTS 6
DSR 6 57 RTS 6
DCD 6 58 GND
TXD 7 59 CTS 7
DTR 7 60 RTS 7
GND 61 CTS 8
TXD 8 62 RTS 8
DTR 8
If you see this or a similar information the device is installed correctly.
AUFBAU
S1-S4: 62 Pin Stecker zu 8x 9Pin
BESCHREIBUNG & TECHNISCHE DATEN
Die EX-41088 ist eine PCI serielle RS-232 Karte mit 8 seriellen FIFO 16C550 Ports, für den
Anschluss von High-Speed seriellen RS-232 Peripherie Geräten (z.B. Terminal, Modem, Plotter
usw.). Der serielle PCI Bus unterstützt dabei optimal die Leistung des schnellen FTDI Chipset.
Die Karte gewährleistet so eine sichere Datenübertragung und exzellente Performance von bis
zu 921,6KBaud/s! Sie unterstützt alle PCI & PCI-X Slots mit 3.3V und 5Volt. Es ist nicht möglich
die I/O Adressen und Interrupts manuell einzustellen, da die Einstellungen der Karte vom
System (BIOS) und vom Betriebssystem automatisch vorgenommen werden.
Kompatibilität:
Betriebssysteme:
Anschlüsse:
Lieferumfang:
Zertifikate:
ANSCHLÜSSE
DB 9M
6
Anleitung
Vers. 1.0 / 05.02.19
Serieller Anschluss
PCI & PCI-X, 5Volt oder 3,3Volt
Windows 9.x/ ME/ 2000/ XP/ Vista/ 7/ 8.x/ 10/ Server 20xx/ Linux/ MAC
8x 9 Pin D-Sub serieller Stecker
EX-41088, Treiber CD, Anleitung
9 Pin Stecker Seriell RS-232
Pin Signal Pin Signal
1 CDC 4 DTR
2 RXD 5 GND
3 TXD 6 DSR
1
EX-41088
Pin Signal
7 RTS
8 CTS
9 RI
