6. Driver Installation
CHECK THE INSTALLED DRIVER
Click at >Start< >Programs< >Administrative Tools[Common]< >Windows NT-
Diagnostics< then click at >Resource< >IRQ<. Here you should find the entry „09
o 0 PCI". Then click at >I/O-Port< here you should see the entries „D400-D407
sysbase 0 PCI" „D800-D802 sysbase 0 PCI" and „DC00-DC1F sysbase 0 PCI"
for the ports. The I/O addresses can change depends which system and card is in-
stalled. If you see these or similar entry's the card is installed correctly.
SCO UNIX / LINUX
The drivers are located in the following folder on our driver CD:
"D:\IO\SYSTEMBASE\DRIVERS\PCI\SCO"
Because each individual distribution and kernel version of Linux is different, sadly we
cant provide a installation instruction. Please refer to the installation manual for stand-
ard IO ports from your Unix/Linux version! In some newer versions of Linux the card will
even be installed automatically after starting Linux.

7. Technical Information

Power Requirement:
Operating Temperature:
Storage Temperature:
Rel. Humidity:
Baud Rate:
Data Bits:
Stop Bits:
Parity:
Flow Control:
RS-232 Signals:
Size:
Weight:
3,3V/900mA
0 to 55°C (32 to 132°F)
-20 to 85°C (-4 to 185°F)
5 to 95% RH
110bps to 921.6Kbps
5, 6, 7, 8, 9
1, 1.5, 2
None, Even, Odd, 1, 0
RTS/CTS, XON/XOFF
TXD, RXD, RTS, CTS, DTR, DSR, DCD, RI, GND
146 x 56mm
1200g
14
EX-41016-2
