3. Press crown race onto the fork steerer until the race is seated snugly against
the top of the crown using a crown race installation tool per the headset
manufacturer's instructions.
4. Clean and grease the headset bearings and races per the headset
manufacturer's instructions.
5. Install the lower bearings (if applicable) on fork crown race per the headset
manufacturer's instructions.
6. Insert the steerer tube into the head tube of the frame.
7. Install the upper bearings, stem spacers, and stem.
8. Install the stem cap and bolt. Tighten the bolt to headset manufacturer's
specifications.
9. Install the handlebars and torque the stem pinch screws or stem clamping
system to stem manufacturer's specifications.
10. Install the brakes and adjust per the brake manufacturer's instructions.
11. For forks equipped with a MILO remote lockout lever, install the lever in an
easily accessible position and torque to values indicated in this manual on
Table 2.
12. a. For forks with standard dropouts (non through axle), the quick release must
be tightened to quick release manufacturer's specifications after it is properly
seated into the dropout counter bores. Refer to your bicycle owner's manual
on the proper use and adjustment of the quick release lever. NOTE: Forks with
standard dropouts are equipped with a secondary catch dropout to retain the
wheel in the fork in the event the quick release comes loose.
b. To install the 20mm Hex Axle, simply slip the axle into the dropout, small
axle hex side first into the large dropout hex. Thread in the set bolt into the
small hex side and snug slightly. Push the fork up and down a few times to
center the axle and hub. Tighten drive side pinch bolts first, then the end bolt
and finally disc side pinch bolts. Tighten all bolts to recommended torque
values found in this manual.
c. To install the QR15 axle please refer to the QR15 Installation section in this
manual.
13. Install the brake cable per manufacturer's instructions.
FAILURE TO PROPERLY ROUTE AND SECURELY ATTACH THE FRONT
BRAKE CABLE TO THE FORK CAN CAUSE SERIOUS INJURY OR
DEATH.
5
