8.4 Adjusting the
Standard Footplates
The Leckey Horizon Stander
footplates are split to allow independent
height and angle adjustment for exact
positioning of both feet. To adjust the
footplate height first loosen the allen bolts
(a) and then slide the footplate to the
required position and retighten securely.
To alter the angle of the footplate to
accommodate plantarflexion or dorsiflexion
simply rotate the coupling cylinder clockwise
or anti clockwise respectively (b).
A
B
8.5 Adjusting the
Flip-up Footplates
The footplate is hinged at the front which allows
the sandals to be adjusted more easily and
can facilitate transfer from a seating position to
prone standing. To avoid any possible finger nip
issues lift the footplate at the notched area.
Use caution when lifting and
lowering the footplate as fingers
could become trapped.
8.6 Adjusting the 3D
Footplates
Loosen the three screws at the bottom of the
ball and socket joint (a). Swivel and adjust
footplate to required position and tighten
screws.
The footplate can also be adjusted to
accomodate leg position by loosening screw
(b) then you can slide left, right, backwards
and forwards. To move footplate up and
down, loosen the screw at the front of the
footplate, slide into position and retighten (c).
A
B
C
