Multi-tool
A number of adjustments will require the
use of the multi-tool, which is supplied with
each product.
Charging the battery
Before the product is used for the first time
it is recommended to charge the battery fully
for at least 12 hours. To charge the battery
(a), plug the adaptor into the mains socket,
attach the lead to the frame and switch on
the mains power. While charging, the charger
LED will remain orange and will turn to green
when fully charged. When charged switch
off mains power, remove the adaptor plug
and disconnect the lead from the frame. The
battery charge should be topped up each
day for approximately one hour.
If the battery is low in power an audible
bleep will sound indicating that it needs to be
charged. 'Battery low' will also be indicated
on both handset and control box (b).
Setting the Angle
Whether used in supine or prone the frame
angle can be easily adjusted with the push
button control handset or the control box.
Use angle indicator on frame for guidance.
Ensure that the product and user are away
from surrounding furnishings to prevent
possible collisions when adjusting the angle.
Safety first
Keep polythene bags away from children.
B
7.1 How to attach the
tray in prone standing
The tray is attached to and removed from
the frame by sliding the square metal tube into
the top of the main spine. Before you insert the
tube unlock the locking lever (a), insert the tube
and relock the lever.
To lock the tray and set its height push the
locking lever (a) down until it touches the metal
spine. After use the locking lever needs to be
fine tuned to ensure secure locking. To do this
lift up the lever and turn the nut (b) while holding
the lever in a fixed position. Push the lever back
down to check if it locks the tube securely.
Repeat the process as necessary.
A
B
Always use caution when making this
adjustment, as fingers could become
trapped in the receiving tube while
positioning.
A
