Extension Operation

Active Extension Operation via Insert 6805 U
The "active" extension functions in the same way as the
master. However, the set overtravel times of the master
and extension add up.
Therefore, we recommend,
- setting the short-time impulse on the 6805 U and
- the desired overtravel at the master.
93

Fault Elimination

Diagnosis Cause/Remedy
Unscheduled - Animals (e.g., cats) traverse
switching: the detection zone.
- Heat is introduced into the
detection zone as a result of
reflection from light-coloured
walls or reflected surfaces,
modify the detection range
by covering the area
concerned with the masking
strip provided.
FM Sensor does not - Frontal approach; select an
detect laterally and only optimuminstallation site.
at short range:
91
GB Fault Elimination
Diagnosis
FM Sensor
does not switch on:
Light is not on:
90
94
GB
Fault Elimination
Diagnosis
FM Sensors 6800-xxx- - Change load combination.
102M/103M/104(M)
switch off involuntarily: - Reduce load.
Light switches ON
and OFF continuously: - FM Sensors actuate
Unscheduled switching: - Switching on after mains
93
GB
Cause/Remedy
- Response threshold is set too
dark in a bright room or with
artificial light. Turn setscrew
in the direction of "bright".
- Lens is covered or soiled.
Uncover lens, clean with a
damp cloth.
- Series element or fuse is
defective. Check and replace.
- Line is broken; measure
and repair.
- Replace defective lamp.
- Replace line-side fuse/
switch on again.
- Repair incoming line.
- Install at correct height.
- Replace defective FM
Sensor.
91
GB
Cause/Remedy
(only with 6590 U-10x)
(only with 6590 U-10x, 6804)
FM Insert 6401 U-10x only:
transformers, relays/
contactors without surge
arrester, fluorescent and
economy lamps; install an RC
element (Type No. 6899)
parallel to connected consu-
mer.
failure:
A period of approx. 80
seconds is normal in the case
of Type 6810-21x-xxx.
94
92
Fault Elimination
Diagnosis Cause/Remedy
Light is always on: - Constant movement in the
detection zone; remove heat
source from the detection
zone and wait until the
switch-off delay time has
elapsed. To test, the lens can
also be completely covered.
- FM Sensor is bridged by
switch arranged in parallel.
- Types 6800-xxx-102M/103 M/
104(M): reset slide switch to
"automatic".
Light switches ON and - Distance to connected
OFF continuously: luminaires is too short;
increase distance to luminai-
res or cover lens in the
direction of incidence with
the masking strip provided.
95
Fault Elimination
Diagnosis Cause/Remedy
Unscheduled switching: - Types 6800-xxx-102M/103M/
104(M): Is normal for the set
switch-off delay period.
- Switching on after mains
failure.
FM Sensor does not - 6800-7x-102M/104M
detect laterally and incorrectly installed.
only at short range: After installation,the terminal
screws of the FM insert must
be in the correct position -
refer to tabular overview on
Page 75.
