Prior to fi rst use
Before you use the device, you must do the following:
• unpack the product contents,
• assemble the device.

Unpacking

❐ Keep children and pets away from the packaging. There is a danger of
suffocation!
• Unpack all parts and make sure that the product contents are complete (see chapter "Prod-
uct contents") and check for any damages from transport. If you identify damages to the com-
ponents, do not use the device (!), instead contact our customer service centre (see chapter
"Customer service").

Assembly

For assembly, you will also need a star-headed screwdriver.
Align the
holes
Screwing
Screwing
1. The fresh water tank (3) has already been installed in the
midsection. Remove it before assembly by fi rst depressing the
release button (2) and then pulling it out.
Mount the midsection on the main unit as shown.
2. Insert the handle in the opening on the midsection and align it so
that the curved end of the handle is on the back of the device.
The handle will lock into place in the right position.
3. Screw the 3 enclosed screws into the threading on the back of
the midsection (see fi gure) and tighten them with a star-headed
screwdriver.
Screwing
4. Turn the hook of the upper cord bracket up.
5. Insert the connecting piece on the bottom of the fresh water
tank in the ring on the bottom of the midsection. Push the top
part of the tank against the midsection until the catch audibly
locks into place.
Carpet Cleaner.
You have now assembled your
17
"Clean Maxx"
