IKA RV 10 control Betriebsanleitung Seite 4

RV 10 control
Komplettaufbau mit Zubehör Schutzschild HB 10.1 und Schutzhaube HB 10.2
Device complete, incl. accessories HB 10.1 spray guard and HB 10.2 cover
L'appareil complet, incl. les accessoires HB 10.1 bouclier anti-projections et HB 10.2 capot de protection
G
F
E
D
Pos. Bezeichung
A HB 10.2 Schutzhaube
B HB 10.1 Schutzschild
C HB 10 Heizbad control
D RV 10 Antrieb control
E Glassatz
F Halter
G Woulff'sche Flasche
Funktionstasten / Function keys / Touches de fonction RV 10 control
1
2
3
Pos. Bezeichung
1 Taste "Power"
2 Taste Liftposition "L"
3 Taste Liftposition "M"
4 Dreh-/ Drückknopf
5 Taste "Set"
6 Taste "Esc"
4
Item Designation
A HB 10.2 Cover
B HB 10.1 Spray guard
C HB 10 Heating bath control
D RV 10 Drive control
E Glassware
F Bracket
G Woulff bottle
Item Designation
1 "Power" key
2 Lift position "L" key
3 Lift position "M" key
4 Rotating/ Pressing knob
5 "Set" key
6 "Esc" key
A
B
C
Fig. 1
Pos Désignation
A HB 10.2 Capot de protection
B HB 10.1 Bouclier anti-projections
C HB 10 Bain chauffant control
D RV 10 Entraînement control
E Verrerie
F Support
G Flacon de Woulfe
6
5
Fig. 2
Pos. Designation
1 Touche "Power"
2 Touche de position du dispositif de levage "L"
3 Touche de position du dispositif de levage "M"
4 Bouton rotatif/ Bouton-poussoir
5 Touche "Set"
6 Touche "Esc"
4
042009
