Maintenance works

2. Dismantling housing (Fig. 4, Page15 )
Dismantle driver's cab (1):
Using a small screwdriver, unclip the 4 mounting clips by lifting
upwards. Remove the driver's cab upwards.
Dismantling the casing front / back (3):
Slightly squeeze casing to release the mounting clips. Remove the
casing upwards.
3. Exchanging the circuit board (Fig. 4,Page 15)
Remove casing, see item 2.
Unscrew the two mounting screws. Slightly tip the circuit board (7)
and unsolder the power supply cable (8). Unsolder the cable from
the motor (9) to the circuit board.
Note: Make a note of how the cables were soldered –
otherwise direction may be wrong.

4. Lighting

This locomotive is fitted with maintenancefree lightemitting di­
odes. If a defect occurs in the lightemitting diodes, please contact
your specialist dealer or the manufacturer.
5. Exchanging the motor (Fig. 4, Page 15)
Remove housing and circuit board, see item 2 and 3.
Unsolder motor cables (9) from circuit board (7). Unscrew moun­
ting screws (8) front / back and remove weights
(13 / 14). Unclip bogie attachment (15) with a small screw driver.
Remove endless screw (16) and cardan shaft (17) from their
holders. Remove bogie (18) downwards. Pull tank (19) off the
underside (fastened with adhesive tape). Using a screwdriver, push
engine bearings (20) upwards from the bottom plate (21), remove
engine (22) with both motor bearing halves.
Caution: When removing the engine, please note the installation
position, otherwise direction may be wrong.

6. Maintenance work on the upper gear part

(Fig. 4, Page 15)
Dismantle casing and circuit board, see item 2 to 3. Unscrew
mounting screws (12) front / back and remove weights. Unclip the
bogie attachment (15) with a small screwdriver. Remove endless
screw (16) and cardan shaft (17) from holder.
