10. Conversion to digital operation (Fig. 4, Page 15)
DC version
Remove housing, pull off dummy connector (34) and insert digital
decoder (33).
Please consult the installation instructions issued by the
decoder manufacturer for correct installation of the digital
decoder and its insert direction.
AC version
The premium digital decoder (33) is standard for the alternating
current (AC) locomotives models. The decoder independently
identifies the operation type (analog/digital). Please refer to the
enclosed installation and operation instructions "Premium Digital
Decoder" in the event that the decoder needs to be reprogrammed.
The decoder is set to address 03 in the factory.

Function keys for Soundmodels

F0 Light ON/OFF
F1 Sound ON/OFF
F2 Airhorn 1
F3 Ventilator while driving ON/OFF
F4 Switchable backlights
F5 Coupling/Decoupling procedure
F6 Shunting mode
F7 Greasing
F8 Compressor
F9 Sanding
F10 Brake
F11 Airhorn short
F12 Diesel notch up
F12 Diesel notch up/down
F13 Diesel notch down
F14 Safety Valve
F15 Ventilator manual ON/OFF
Note:
Please note exactly where and how each individual part was
mounted. The mounting position is also indicated on the spart
parts graph on page 16 / 17.
