who have been trained in the use of the machine and ha-
ve been informed of the various dangers may work with the
machine. The required minimum age must be observed.
In addition to the safety requirements contained in these
Operating Instructions and your country's applicable regula-
tions, you should observe the generally recognized technical
rules concerning the operation of woodworking machines.

General notes

• After unpacking, check all parts for any transport da-
mage. Inform the supplier immediately of any faults.
Later complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
• Use only original accessories, wearing or replace-
ment parts. You can find replacement parts at your
scheppach dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
HC 54
Package contents
Technical Data
Max. working pressure in bar
Oil quantity l
Filling capacity (FAD) l/min.
Air exchange(PD) l/min
Weight kg
Drive
Motor in V/Hz
Input power in W
Output power in W
Rotational speed in 1/min
Sound pressure level L
pA
Sound Power Level L
WA
Ambient temperature
Subject to technical modification!
Legend, Fig. 1
Get to know your device
1 Handle
2 Pressure switch cover
3 ON/OFF switch
4 Tank manometer
5 Adjustment knob
6 Adjustable drain valve
7 Adjustable drain valve gauge
8 Safety valve
9 Backflow locking valve
10 Condensation water drain plug
11 Air tank
12 Wheel (2x)
13 Safety sign
14 Oil inlet plug
15 Air filter unit
16 Glass sight gauge for oil level
17 Oil drain plug
Compressor HC 54
2 Wheels
1 Air filter
1 Accessory bag
Operating instructions
8,0
0,25
158
ca. 220
31,0
230/50
1500
1100/1500 maxx.
2850
71,2 dB(A)
91,2 dB(A)
5 - 35°C
