Make sure that the individual wires are connected and allocated
correctly before the electrical wiring. If necessary, ask an expert.
The device does not need a protective earth connection. If neces-
sary, cut it.
• Open the screws of the contact strip and insert the wires until the insulation
is above the edge of the contact surface in the terminal. Hold in position
and tighten the screws. If you cannot push the wire into the terminal strip
far enough, check the length of the end splice. After assembling, check and
re-tighten all the screws.
• Fasten the cover with screws to front of the contact strip.
• Insert the switching logic into the wall-mounted relay part. Make sure that
labels and display are legible and not in an upside down position. If this is
the case, the parts are not in proper contact. The switching signals are trans-
ferred from the logic to the relay part by way of three contacts.
