Make sure that the batteries/rechargeable batteries are inserted the
right way. Contact with batteries/rechargeable batteries that are dead or
damaged can cause skin irritation. Use protective gloves in this case.
Do not short-circuit the batteries/rechargeable batteries! Do not throw
batteries/ rechargeable batteries in the fire.
There is a danger of explosion!
Never take a battery/rechargeable battery apart!
Never attempt to charge normal batteries. There is a danger of explosion!
If not used for any length of time (e.g. when in storage), remove the
batteries/ rechargeable batteries to avoid damages caused by leaking, etc.
Always replace all batteries/rechargeable batteries in the device and use batteries/
rechargeable batteries of the same type/from the same manufacturer only.
Do not mix batteries with rechargeable batteries.
Used batteries are not to be disposed of with the house-hold waste!
Please dispose them at your local battery collection point!
7
Start up
7.1
Adapting the door drive to the used lock
The scan/request for and the entry of basic settings is generally to be done
when initially starting up and must be done completely (all menu points).
All menus can be aborted by pressing and holding any button. All menus are abor-
ted automatically after approx. 3 minutes without pressing a button. (therefore, do
not allow too much time to pass between menus).
For starting the scan/input of basic settings, e.g. if more than3 minutes have past
since inserting the batteries, or if you want toinstall a new lock cylinder) press the
smallround button "Setup" for approx. 2 seconds.
If a master remote control has already been taught, you have to authenticate it to
change the basic settings with the master remote control.
The device LED of the master remote control is illuminated in red when
authenticating!
In order to simplify setup work, every step in configuring the display content and
the buttons to be pressed for the door lock drive are provided in the following
description.
At the beginning of the scan/input, the display shows "1" for the first setup step (see
following) and the symbol "locked" (
40
) and then the rotating direction symbol.
7.1.1
Choosing the direction of rotation
Use the handwheel to test the lock and the lock cylinder on your door
to determine which rotational direction is used for locking (bolt moves
outward).
Use the bottom button to change the direction of rotation to "left".
The line in the LC display rotates to the left to indicate direction of rotation
"to the left".
Use the top button to change the direction of rotation to "right".
The line in the LC display rotates to the right to indicate direction of rotation
"to the right".
Choose the desired direction of rotation by briefly pressing the respective
button.
Remember: If the door has not yet been opened, open it now so that the
end stop is detected later.
In order to get to the next menu point, briefly pressthe small round button
"Setup" with a pointed object and the initialization move (see next section)
begins.
The display shows "2" to indicate the second setup step.
7.1.2
Setting "Unlocked"/"Locked", Door latch hold time
Wait until the first initialization move. During the initialization move, the drive moves
against the stop several times in the direction "Unlock". The door latch should be
completelyretracted in this case.
At the end of this process, the drive moves to the self-detected position "Unlocked".
This setting can be changed in 90 degree steps to suit the individual
requirements of the drive:
• In order to use predominantly as a door opener, move the setting further
toward "Unlocked" to minimize the time for retracting the door lock-latch.
• In order to use predominantly for locking and unlocking, move the setting
further toward "Lock", to keep the travel distance and therefore the
battery consumption low. This makes sense e.g. on doors that have a
door latch on the outside as well.
41
