7.4.2
Replacing the master remote control
If the "Master" remote control is lost or is defective, another remote control can be
taught as the "Master remote control. Proceed as follows in this case:
• Remove the door lock drive from the door by unscrewing the fastening
screws to disconnect it from the base fastener.
• Press the button "Unlock" for approx. 2 seconds. The LC display shows
"X", the symbols for radio reception and "Unlock" flash.
• Turn the handwheel 10 turns in direction "Lock".
• The display shows memory location "1" (selecting another memory
location is not possible!).
• Set the remote control to configuration mode and briefly press one of the
buttons of the button pair to be taught.
If the new "Master" remote control was already taught in another memory
location, this is automatically cleared/deleted.
After installing the drive again, run a complete door lock drive setup for the
used lock.
7.4.3
Resetting the device to factory status
In order to reset the door lock drive back to factory status, proceed as follows:
• Remove the door lock drive from the door by unscrewing the fastening
screws to disconnect it from the base fastener.
• Press the button "Setup" for approx. 2 seconds. The display shows "X".
• If you have access to the Master remote control, press any button, that is
assigned to the KeyMatic, and the "X" disappears.
• If you do not have access to the Master remote control, turn the hand-
wheel 10 turns in direction "Lock". The "X" disappears from the display.
• Turn the handwheel 10 turns in direction "Lock".
• The direction of rotation selection is shown on the display (the door lock
drive is in factory status and must be set up to the door lock again).
After installing the drive again, run a complete door lock drive setup for the
used lock.
46
8
Operation
Door lock drive operation is possible in three different ways:
• Device operation
• Operation via the HomeMatic Radio hand transmitter/remote control
• Operation with the HomeMatic Centre
The action (Lock, Unlock or Open) is shown on the display of the door lock drive.
The last method of operation is also shown.
M
Operation with the buttons on the device
1 - K
Operation with a HomeMatic remote control, the letter/number shows the
memory location of the remote control used for the operation.
c
Command from the HomeMatic Centre
Briefly pressing the button pair that has been taught can be used for locking and
unlocking, a longer press of the "Unlock" button can be used for opening the door.
8.1
Normal operation
8.1.1
Locking
The following describes operation on the device. The same behavior applies for
operation with a remote control and with the Centre but a different letter/number is
shown on the display (see previous section).
Press the button "Lock" on the door lock drive (bottom button).
"M" is shown on the display.
The lock bolt moves to the previously defined locking position and thesymbol "Lo-
cked" (
) appears. Upon completion of the procedure, a long signal tone is emitted
on the door lock drive.
If the lock has been turned on the inside with the handwheel or with a key
fromoutside in the meantime, for safety reasons it does not move to the
"Locked" position but turns to the stop in the direction "Locked" instead.
A jammed lock is (after previous manual actuation with the handwheel or with the
key) is recognized as stop "Locked" if necessary. In this case, the symbol "Locked"
(
) may be shown and the acoustic acknowledgement signal may be emitted, alt-
hough the lock is not fully locked.
47
