Mounting
During the initial start up, the door lock drive starts by requesting the basic
settings after inserting the batteries.
These basic settings are absolutely necessary for the initial start up so that the
door lock drive will operate correctly. Perform all set up work correctly and careful-
ly so that proper functionality is guaranteed (see sec. „6 Start-up" on page 39).
The basic settings do not have be performed again either if the door lock drive
is to be replaced on another lock cylinder or another door is installed.
Remove or change used batteries immediately to prevent the batteries from
leaking.
When battery power is low, the LC display shows a flashing battery symbol
( ). The device will also emit three warning tones after every basic function
actuated.
Change the batteries/rechargeable batteries in this case. The settings will not
be lost.
Make sure that the batteries/rechargeable batteries are inserted the right way.
Contact with batteries/rechargeable batteries that are dead or damaged can
cause skin irritation. Use protective gloves in this case.
Do not short-circuit the batteries/rechargeable batteries! Do not throw batteries/
rechargeable batteries into a fire. Doing so will present a risk of explosion.
Never take a battery/rechargeable battery apart!
Never recharge standard batteries. Doing so will present a risk of explosion.
If not used for any length of time (e.g. when in storage), remove the batteries/
rechargeable batteries to avoid damages caused by leaking, etc.
Always replace all batteries/rechargeable batteries in the device and use
batteries/rechargeable batteries of the same type/from the same manufacturer
only. Do not mix batteries with rechargeable batteries.
Used batteries should not be disposed of with regular domestic waste!
Instead, take them to your local battery disposal point.
38
6

Start-up

6.1

Adapting the door drive to the used lock

Please read this section entirely before starting to use the device!
The scan/request for and the entry of basic settings is generally to be done when initially
starting up and must be done completely (all menu points).
All menus can be aborted by pressing and holding any button. All menus are aborted
automatically after approx. 3 minutes without pressing a button.
For starting the scan/input of basic settings, e.g. if more than 3 minutes have passed
since inserting the batteries, or if you want to install a new lock cylinder, press the
"Setup" button (C) for approx. 2 seconds using a pointed object.
If a master remote control has already been taught-in, you have to authenticate
it to change the basic settings with the master remote control. The device LED
of the master remote control is illuminated in red when authenticating (see sec.
„6.3 Teaching-in" on page 42).
In order to simplify setup work, every step in configuring the display content (E) and the
buttons to be pressed for the door lock drive are provided in the following description.
At the beginning of the scan/input, the display shows "1" for the first setup step and the
symbol "locked" ( ) and then the rotating direction symbol.
6.2

Choosing the direction of rotation

Use the handwheel (B) to test the lock and the lock cylinder on your door to
determine which rotational direction is used for locking (bolt moves outward).
Use the bottom button to change the direction of rotation to "left".
The line in the LC display rotates to the left to indicate direction of rotation "to the
left".
Use the top button to change the direction of rotation to "right".
The line in the LC display rotates to the right to indicate direction of rotation "to
the right".
Choose the desired direction of rotation by briefly pressing the respective button.
If the door has not yet been opened, open it now so that the end stop is detected
correctly later.
In order to get to the next menu point, briefly press the "Setup" button (C) with a pointed
Start-up
39
