3.2
Scope of delivery
• Radio door lock drive with base fastener and 2 wood-screws
• Allen key for installing the base fastener and the radio door lock drive
• Three batteries of type Mignon/AA/LR6 (for radio door lock drive)
• Operating manual
4
General system information on HomeMatic
This device is a part of the HomeMatic home control system and works with the
bidirectional BidCoS
®
wireless protocol.
All devices are delivered in a standard configuration. The functionality of the device
can also be configured with a programming device and software. Further resulting
functionality and the additional functions provided in the HomeMatic system
combined with other components are described in the separate Configuration
Instructions and in the HomeMatic System Manual.
All current technical documents and updates are provided under www.HomeMatic.
com.
5
General information on radio operation
The radio transmission is on a non-exclusive transmission path which means that
there is a possibility of interference occurring.
Other interfering sources can be caused by switching operations, electrical motors
or defective electrical devices.
The range of transmission within buildings can greatly deviate from open air
distances. Besides the transmitting power and the reception characteristics
of the receiver, environmental influences such as humidity in the vicinity and
local structures also play an important role.
Hereby eQ-3 Entwicklung GmbH, declares that this device conforms with the
essential requirements and other relevant regulations of Directive 1999/5/EC.
The full declaration of conformity is provided under www.HomeMatic.com.
32
6
Installation
6.1
Requirements on the door and the used lock cylinder
Door requirements:
The door lock drive can only be used on doors with locks and bolts that move easily
and do not jam.
Please note!
Doors with locks that can only be operated by pushing, pulling, lifting,
lowering or twisting the door are not suitable for operation with the door
lock drive!
• Note, especially with wooden doors, the weather can cause the door to
warp, which can in turn make the door unsuitable for locking and unlocking
operation with the door lock drive at times. The door lock drive cannot
handle the forces that are required by a warped door on the door latch.
• Make sure that the door can be locked and unlocked smoothly and easily
under all climatic conditions before implementing the drive. This can be
tested by locking and unlocking the door lock with the key and without
using the door handle. Set the door hinges and/or the striking plate in the
door frame so that locking and unlocking is smooth and easy with the key
as described previously.
• In order to use the door opening function of the KeyMatic system, the door
seals must be intact and designed so that the door will open on its own after
completely unlatching the lock because of the expansion of the door seal.
Lock cylinder requirements:
The door lock drive is attached directly on the lock cylinder and moves the cylinder
with the respective key inserted. Therefore, the lock cylinder must be designed so
that it protrudes inside the door by 8 - 15 mm past the inside door fittings.
Determine the dimensions of the required lock cylinder using the following diagram.
When choosing the lock cylinder, the dimensions "Inside" (Inside cylinder dimension)
and "Outside" (Outside cylinder dimension) are important. In each case, measure
from the fastening screw of the cylinder in the lock fitting (including the door fittings)
and add 8 - 15 mm to the inside dimension to calculate the suitable standard
dimensions.
Example: You measure an outside dimension of 40 mm and an inside dimension
of 40 mm as well. Therefore, the cylinder is a 40/40 cylinder. In order to use the
KeyMatic drive, you therefore need the next standard size, a 40/50 cylinder. The
cylinder will then protrude inside by 10 mm.
A lock cylinder with integrated LED can be obtained as an accessory.
