Configuration, PC Program

The configuration of the Analog/ISDN Converter is
made via the USB interface of an attached PC.
The previously installed driver "Virtual COM Port
(VCP) Driver" imitates the function of a serial inter-
face so you have to select one of the existing COM
ports in the PC program.
Which of the existing interfaces in your PC is con-
nected, can be determined by looking into the
device manager of the control panel. You can start
it with the key combination WINDOWS+BREAK or
depending on the operating system as follows:
– Windows 2000: Start + Settings + Control
Panel + System + Device Manager
– Windows XP: Start + Control Panel + System
+ Hardware + Device Manager
– Windows Vista: Start + Control Panel (Classic
View) + Device Manager
You cannot reset the administrator pass-
word.
The device has to be sent to Auerswald
for resetting the administrator password.
For a first time configuration of the Analog/ISDN
Converter, please proceed as follows:
1. Start the corresponding PC program.
2. Close the dialogue Open Configuration by
clicking Cancel.
3. Click Options and Interface... in the menu.
4. Select the correct COM port.

Selection of the Interface

General Advice for the PC Program

Configuration, PC Program
5. Click the button for a new file. Now an "empty"
configuration opens.
6. Make the necessary settings in the configura-
tion.
7. Click the button for saving a configuration.
8. Click Converter to transfer the configuration
into the Converter.
