The Analog/ISDN Converter enables you to attach
an ISDN PBX or another ISDN device to two ana-
log connections.
You can connect the device with up to two analog
connections of your network provider and to an
external S
port of an ISDN PBX.
0
If you connect the PBX to an additional ISDN net-
work connection via a second external S
Analog/ISDN Converter has to be connected to
the existing NT for ISDN synchronization.
To make the necessary configuration settings with
the corresponding PC program a PC connection is
available.
The scope of functions described here is
only completely usable with a profes-
sional installation and a correct configu-
ration of the system. We highly recommend to
consult your authorized dealer first.
Please ask your network provider about the avail-
ability of some features. Some of these functions
may be available for an extra fee.
There may be incompatibilities in combination with
devices of other vendors that may influence the
usability of features.
Features
Point-to-MultiPoint connection (PTMP) and
Point-to-Point connection (PTP)
Translation of ISDN features to features of the
analog public exchange line
1 device Analog/ISDN Converter
1 ISDN connection cable RJ-45 (8P/4C) to
RJ-45 (8P/4C)
2 connection cables RJ-11 (6P/4C) to RJ-11
(6P/4C)
in Germany 2 adapters RJ-11 to TAE-F
1 USB connection cable
Liquids entering the case may cause a
dangerous electric shock or may dam-
age or destroy the device.
- When cleaning the case, make sure to pre-
vent liquids from entering the case.
Usage and Functionality
port, the
0
Analog exchange line features supported
by the device
and CLIP of the analog public exchange line will
be supported.
Scope of Delivery
Cleaning of the Case
Protect the device against dirt, dust and splash. If
a cleaning should be necessary, wipe the case
with a slightly damp cloth or use an antistatic
cloth.
Support of the ISDN services Speech, 3.1 KHz
Audio (analog), Telephony 3.1 KHz and fax
Group 2/3
Protection against unauthorized programming
by an administrator password
Busy tone detection
Firmware update via PC
Configuration via PC
Three-party call (3PTY)
Query, alternation (HOLD)
Call forwarding (CFU, CFB, CFNR)
Call back on busy subscriber (CCBS)
Call charge pulse (12/16 kHz or AOCD)
Suppress outgoing number transmission
(CLIR)
Calling number presentation (CLIP) numeric
Calling name presentation (CNIP) alpha-
numeric
Transfer of date and time
If the connection to the ISDN device is
configured as a Point-to-Point connec-
tion, only the features AOCD, CLIR
1 wall-mounted power supply
mounting material (screws and dowels)
1 data medium (Auerswald Mega Disk)
1 installation and user manual
1 warranty declaration
1 drilling template
33
Introduction
