34

LED Displays

The LED "S0 activ" shows the state of the S
in case of a connection to the PBX. If the S
ready for operation (Layer 1 active), the LED
glows green.
The LED "Sync activ" shows the state of the S
port in case of a connection to the NT. If the S
is ready for operation (Layer 1 active), the LED
glows green.
Power Supply
Rated voltage 230 V
for wall-mounted power supply
Type number of wall-
mounted power supply VD100055H
Rated current 80 mA maximum
Protection class
II
Temperature Range
Operation +0...+40°Celsuis, avoid direct
sunlight!
Storage and shipping -20...+70°Celsius
Humidity 10 - 75%, non condensing
Analog connection
Connection 2 analog inputs
Connection unit optionally 2 RJ-11 jacks (6P/4C) or
terminal clamps (2 x 2-core)
Type of dialling pulse dialling or DTMF
Ringer frequency 25/50 Hz
Charge pulse switchable 12/16 kHz
Impedances switchable
600
900
220 +820 / 115 nF (Germany)
370 +620 / 310 nF (UK)
180 +910 / 150 nF (France)
270 +750 / 150 nF (EU, Sweden)
120 + 820 / 110 nF (Norway)
150 + 830 / 72 nF (Belgium)
400 + 500 / 330 nF (Denmark)
1) Starting with Hardware revision 2 (Rev. 2) the wall-mounted
power supply DV-10W3UP will be used instead of VD100055H.
LED Displays
port
0
port is
0
port
0

Technical Data

10%, 50 Hz
1)
(Austria and Spain)
The LED "busy" shows the operation of the corre-
sponding analog line. If the line is busy, the LED
glows red.
The LED "Power" shows whether the device is
switched on. If the connection to the 230 V socket
0
is established via the wall-mounted power supply,
the LED glows green.
ISDN Connection
Connection
Connection unit
Connection type
Number of devices
Terminators
ISDN synchronization
Connection
Connection unit
Connection type
PC connection for configuration
Interface
Miscellaneous
Case
Dimensions
Weight
Safety
1 S port
0
optionally 1 RJ-45 jack (8P/4C) or
terminal clamps (4-core)
S basic access as Point-to-
0
Multipoint connection or as Point-to-
Point connection, EURO-ISDN
(DSS-1)
max. 3 ISDN devices, all devices
self-powered
switchable
1 port for synchronization
optionally two RJ-45 jacks (8P/4C)
or a terminal clamp (4-core)
S basic access as Point-to-
0
Multipoint connection or as Point-to-
Point connection, EURO-ISDN
(DSS-1)
USB (V 1.1)
plastic, chassis with cover
217 mm x 157 mm x 65 mm
(W x H x D)
approx. 580 g (without wall-mounted
power supply),
wall-mounted power supply approx.
400 g or 570 g
EN 60950, CE
