PREPARATION

INSTALLING THE FILTERS

To maintain the quality of the filters, they are installed in the main unit within plastic
bags. Be sure to remove the filters from the plastic bags before using the unit.
1
Remove the filters
1
Place the unit facing up.
Lay the unit on a table, etc., while
making sure not to pinch the
power cord on the rear of the
unit.
2
Remove the Front panel.
Press in the hook on the bottom
of the Front panel and lift to re-
move.
3
Pull out the Filter frame and
remove the Pre-filter and Fil-
ter separator.
4
Remove the Active carbon
filter (black) and HEPA filter
(white) from the plastic bag.
FU-55SE_Eng.6.5
• Be sure to remove the power plug from the wall outlet.
Be sure to remove the power plug from the wall outlet.
1
E-8
8
Table
2
Hook
Filter frame
Pre-filter
Filter separator
Active carbon filter
HEPA filter
Filter frame
03.7.17, 8:53 AM
Soft cloth
1
Front panel
