Scheppach HM254 Originalbetriebsanleitung Seite 25

21. 1 x Allen key, 6 mm
22. 1 x Allen key, 3 mm
1 x Sliding cross-cut mitre saw
1 x Operating manual
* = may not be included in the scope of delivery!
5 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
6 Technical data
Rated voltage
Nominal power
Power consumption
Operating mode
Protection class
Idle speed n
0
Carbide saw blade
(48 teeth)
Carbide saw blade
(60 teeth)
Saw blade body thickness
Maximum tooth width of the
saw blade
Pivot range
Mitre cut
Saw width at 0°
Saw width
at 0° with 45° mitre
Saw width
at 0° with 45° tilt
220 - 240 V~
50 Hz
S1* 2000W
P 2400 W
1
P S6** 20%
2
II /
4500 rpm
ø 255 x ø 30 x 2.8 mm
ø 255 x ø 30 x 2.8 mm
1.8 mm
2.8 mm
-45 ° / 0° / +45 °
0° to 45° to the left
340 x 90 mm
240 x 90 mm
340 x 45 mm
www.scheppach.com
Saw width at 2 x 45°
(double mitre cut)
Weight
Subject to technical changes!
*Operating mode S1 (continuous operation)
The product can be operated continuously with the speci-
fied power.
**Operating mode S6
Uninterrupted periodic operation. The mode comprises of
a start-up period, a time with constant load and an idle
time. The operating time is 10 mins, the relative duty cy-
cle is 25% of the operating time.
The workpiece must have a minimum height of 3 mm
and a minimum width of 10 mm. Make sure that the
workpiece is always secured with the clamping de-
vice.
Noise data
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Sound pressure level L
pA
Measurement uncertainty K
Sound power level L
wA
Measurement uncertainty K
The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
WARNING
The noise emission values can vary from the
specified values during the actual use of the
power tool, depending on the type and the
manner in which the electric tool is used, and
in particular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Safety instructions
General power tool safety warnings
WARNING
Read all safety warnings, instructions, illus-
trations and specifications provided with this
power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
240 x 45 mm
approx. 12.8 kg
95.5 dB
3 dB
pA
108.5 dB
3 dB
wA
GB | 25
