VEVOR RTP22WS115V Originalanleitung Seite 7

2. The outlet piping should be flexible tubing secured with a hose Clamp (not
provided) or pipe (3/8 inch ID. maximum to prevent excessive flow back to unit).
From condensate unit, extend discharge piping straight up as high as necessary.
Do not extend this line above the head/GPH of the particular model being installed.
From this high point, slope discharge line down slightly to a point above drain area;
then turn down and extend to a point below or approximately level with the bottom
of the condensate unit. This will give a siphoning effect which will improve
efficiency of the condensate unit and will, in most cases eliminate the need for a
check valve (Figure 5). If it is not possible to slope discharge line down, make an
inverted "U" trap directly above the pump at the highest point.
SERVICE INSTRUCTIONS
WARNING
1. Make certain that the unit is disconnected from the power source before
attempting to service or remove any component!
2. Be sure the floats move freely. Clean as necessary (Figure 6).
3. Clean the tank with warm water and mild soap.
4. Check the inlet and outlet piping. Clean as necessary. Be sure there are no
kinks in the line that would inhibit flow.
- 7 -
