Suctioning water
Notes
• WARNING! Electric shock! The device
itself must not be submerged in the water
collector.
• NOTICE! Contamination from back-
washed cleaning agent! Do not draw in
any water from natural accumulations.
• NOTICE! When suctioning, the device
may run dry temporarily.
• NOTICE! Weight down the filter basket
(12) so that it sinks in the water.
Requirements
• Suction hose (11) with filter basket (12)
• standing, clean water (e.g. rain barrel)
Procedure
1. Connect the quick connector (10) of the
suction hose (11) to the coupling (4).
2. Bleeding the suction hose, p. 9
3. Fit an attachment.

Bleeding

Bleeding the supply hose
1. Close the tap.
2. Remove the supply hose from the device.
3. For more, see Establishing a water
supply, p. 8
Bleeding the suction hose
1. Immerse the filter basket (12) completely
into the water collector.
2. Remove the attachment (7, 9).
3. Press the switch lever (2) until the water
comes out without bubbles.

Select the attachment

Nozzles (8) on the lance (9)
Six different nozzles (8) can be used on the
lance (9).
The nozzles can be changed by turning the
nozzle attachment. A small arrow on the top
of the lance indicates which nozzle is selec-
ted.
0°/15°/25°/40° spray angle
Jet sprays upwards
Gentle spray for watering/washing
Cleaning agent nozzle (7)
• Wide fan jet: Low pressure for cleaning
agent

Fitting and removing attachments

Fitting an attachment
1. Attach the desired attachment (7, 9) to
the device (Bayonet locking device: plug
and turn).
Removing an attachment
1. Remove the desired attachment (7, 9)
from the device (Bayonet locking device:
push, turn and pull).

Cleaning using cleaning agent

Requirements for the cleaning agent
• This device has been designed to be
used with a neutral cleaning agent based
on biodegradable anionic surfactants.
• Use of other cleaning agents or chemic-
als can negatively impact the safety of
the device and can cause damage. Such
damage to the device is not covered by
the warranty.
• You can buy cleaning agents from our on-
line shop ( Spare parts and accessories,
p. 14 ).
Requirements
• The cleaning agent tank is filled with
cleaning agent.
Filling/emptying the cleaning agent tank
(6)
1. Twist the cleaning agent nozzle (7) off the
cleaning agent tank (6).
2. Fill or empty the cleaning agent tank (6).
3. Twist the cleaning agent nozzle (7) back
onto the cleaning agent tank (6).

Checking the battery charge level

LEDs
red, orange, green
red, orange
red
1. Press the button (18) next to the charge
level indicator button (17) on the battery
(16).
The LEDs of the charge level indicator
show how much charge remains in the
battery.
GB CY
Meaning
Battery charged
Battery partially
charged
Battery needs to be
charged
