High-pressure jets can be
•
dangerous if used incor-
rectly. The jet must not
be directed at persons,
animals, active electrical
equipment or the device
itself.
Do not direct the jet at
•
yourself or others to
clean clothing or shoes.
Explosion hazard – do
•
not spray flammable li-
quids.
Do not crush or kink the
•
suction hose. There is a
risk of damage and there-
fore a risk of injury to you.
Do not use the device if
•
important parts such as
the suction hose, nozzles
or the spray lance are
damaged.
Protect the device from
•
frost and from running
dry.
To ensure machine
•
safety, only use origin-
al spare parts from the
manufacturer or spare
parts approved by the
manufacturer.

Preparation

WARNING! Risk of injury due to uninten-
tional start-up. Only insert the battery into
8
the device once the device is fully prepared
for use.

Control elements

Familiarise yourself with the operating ele-
ments before using the device for the first
time.
Trigger gun (3)
• Locking mechanism (1)
• Locking the switch lever: Press the
lock (1) while holding down the switch
lever (2).
• Release the lock: Press the switch
lever (2).
• Switch lever (2)
• Press: Activates the water jet
• Release: Deactivates the water jet

Establishing a water supply

You have two options to supply the device
with water:
• Household water connection
• Suctioning standing, clean water, e.g. rain
barrel
Household water connection
Requirements
• System separator
A system separator (check valve) pre-
vents the backflow of water and cleaning
agent into the drinking water pipeline.
• According to current regulations, a
pressure washer must never be con-
nected to the drinking water network
without a system separator. A suitable
system separator must be used in ac-
cordance with EN 12729 Type BA.
• Water that has flowed through a sys-
tem separator is classified as non-pot-
able.
• System separators are available from
specialist dealers.
Procedure
1. Connect the supply hose to the water
supply.
2. Bleed the supply hose: Open the water
supply until the water flows bubble-free
out of the other end of the supply hose.
Close the water supply.
3. Connect the supply hose to the quick
connector on the coupling (4).
