DESCRIPTION OF THE APPLIANCE

1. Top cover
2. Carrying handle with a cord storage
hook
3. Power plug storage slot
4. Accessory storage compartment
5. Power on / off switch
6. Outlet socket for the detergent hose
7. Water feed button
8. Air exhaust
9. Power cable
10. Socket for the detergent hose inlet
11. Hose with a mesh filter and a nut
12. Detergent container
13. Container
14. Tank clamps
15. Air suction inlet
ASSEMBLY AND DISASSEMBLY OF ALUMINIUM TUBES
1. Connect the aluminium tube to the suction hose handle and properly attach the detergent
feed hose (Fig. 1).
2. Connect the two aluminium tubes, as shown here (Fig. 2).
3. Connect the washing attachment to the aluminium tube and connect the liquid supply hose
to the socket (Fig. 3).
4. Press the plastic button on the aluminium tube by hand to disconnect it (Fig. 4).
5. Also press the plastic button on the aluminium tube to disconnect both ends of the tube (Fig.
5).
6. Remove the cleaning attachment from the aluminium tube and disconnect the detergent feed
hose from the socket (Fig. 6).
18
16. Base with accessory storage compart-
ment
17. Small rolling wheels
18. Large plastic wheels
19. Float chamber
20. HEPA filter
21. Sponge filter
22. Suction hose with detergent feed
hose
23. Aluminium tubes
24. Floor and carpet head
25. Large washing attachment
26. Small washing attachment
27. Crevice attachment
28. Paper dirt bag
ASSEMBLY AND USE OF THE VACUUM CLEANER
1. Ensure the power cord is disconnected from the power socket (Fig. 1).
2. Loosen the tank clamps, lift the top cover, and remove all accessories from the tank.
3. Place the cover on the tank, first installing the appropriate filter (Fig. 2):
● For dry vacuuming, install the HEPA filter onto the float chamber by pressing the filter against
the top cover, and attach the paper dust bag to the internal air intake.
● For wet vacuuming or water collection, place the foam filter on the vacuum's float chamber,
ensuring that the filter completely covers the entire float chamber.
4. Close the clamps on both sides of the tank, insert the suction hose into the air intake and
tighten it clockwise, and insert the detergent feed hose into the detergent hose outlet socket.
Connect the aluminium tube to the suction hose handle, properly attach the detergent feed
hose, and attach the selected accessory. Check that they have been installed correctly (Fig. 3).
CAUTION! The hose for feeding the detergent enters the appropriate outlet socket'
"click" ensures the proper mount. Press the white button for dismantling it.
5. Install the detergent container, fill it with water and detergent in proportions according to the
detergent manufacturer's instructions, then insert the hose with the mesh filter into the con-
tainer and screw the cap on clockwise. Connect the hose to the detergent hose inlet socket.
Check whether it has been properly installed (Fig. 4).
6. Connect the power cord to the mains (Fig. 5).
7. For dry vacuuming, press the power switch – the appliance will start operating (Fig. 6).
8. For wet vacuuming or water collection, press the water feed button – the attachment will start
spraying the liquid (Fig. 7). When the power switch is pressed, the dirty water will be suctioned
into the tank. When the tank is full, the safety valve will block further suction. After finishing,
turn off the appliance, unplug it, and empty the tank.
WARNING! When vacuuming wet, do not pour water into the tank! This container will
gradually fill with water during the process of its collection.
When cleaning carpets, use a low-sudsing cleaning agent and add the appropriate an-
ti-foam evenly, otherwise the air outlet may cause foam to escape!
It is recommended to empty the container frequently during intensive washing / liquids
collecting works, in order to prevent a liquid level in the container exceeding critical
levels and creating the possibility of producing foam from the air outlet.
