Index of Contents
1
Amendment History .................................................................. 4
2
General notes ............................................................................ 6
3
General safety instructions ...................................................... 8
3.1
Risk of injury due to rotating shafts .................................................................. 8
3.2
Risk of destruction due to mechanical overload ........................................... 8
3.3
Risk of destruction due to mechanical shock ................................................ 8
3.4
Risk of destruction due to adhesive fluids ...................................................... 8
3.5
Risk of destruction due to soiling ...................................................................... 8
3.6
Explosion risk ......................................................................................................... 8
3.7
Risk of destruction due to external magnetic fields ..................................... 8
4
Electrical Connection .............................................................. 10
4.1
Risk of destruction due to electrostatic charge ............................................ 10
4.2
Interference protection ........................................................................................ 10
5
Warranty Exclusion and Disclaimer ....................................... 10
5.1
6
Scope of delivery ..................................................................... 11
7
Mounting of the rotor ............................................................... 12
7.1
Mounting rotor with shrink fit ............................................................................ 12
7.2
Mounting rotor with gluing fit ............................................................................ 13
7.3
Mounting rotor with set screws ......................................................................... 14
8
Assembly and adjustment of the sensor ............................... 15
9.
Terminal assignment ............................................................... 16
9.1
Square-wave signal-encoder ............................................................................... 16
9.2
Sine signal-encoder .............................................................................................. 16
Baumer_ITDx9_II_OI_DE-EN_1706.indd
Index of Contents
3
