Design of the lympha-mat ® DIGITAL Gradient
Front of device
Interval controller/indicator
set interval between
A1
Select button to
fill the treatment
sleeves at a
standard (>>) or
reduced (>) speed
Rear of device
B3
External
Start/Stop
button
A2
5–90 seconds to
compression cycles
A7 3 connection jacks for sleeves
B2
Power line
~230 V 50/60 Hz with
device protection fuse
2 x T 1.6A
A3
Treatment pressure setting
Pressure indicator 20–120 mmHg
A4
Setting of treatment time 5–60 min
B1 Air vents
lympha-mat
DIGITAL
A5
On/Off switch
A6 Start/Stop switch
