Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
1

Introduction

Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
17
• Installing and replacing non-original spare parts
17
• Improper use
17
• Failures of the electrical system in the event of the
18
electrical regulations and VDE provisions 0100,
DIN 57113 / VDE0113 not being observed.
18
Note:
19
The operating manual is part of this product.
19
It includes important instructions for the safe, proper and
19
economic operation of the product, for avoiding danger,
21
for minimising repair costs and downtimes and for in-
21
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
22
ating manual, you must also observe the regulations ap-
23
plicable to the operation of the product in your country.
23
Familiarise yourself with all operating and safety instruc-
23
tions before using the product. Only operate the product
as described and for the specified areas of application.
24
Keep the operating manual in a good place and hand
24
over all documents when passing the product on to third
25 parties.
75
2

Product description (Fig. 1-12)

1. Carrying handle
2. Container cover
2a. Holder
3. Container
3a. Locking mechanisms
4. Base frame
4a. Holders
4b. Mounting holes
5. Castors
6. Drain cover
7. Suction connection
7a. Fitting port
8. On/off switch
9. Blast connection
10. Filter cage
10a. Safety float valve
11. Vacuum hose
11a. Hose coupling
12. Handle
12a. Slider
13. Suction pipe
14. Floor nozzle
15. Joint nozzle
16. Paper filter bag
16a. Sealing ring
17. Foam filter
3

Scope of delivery (Fig. 2)

Item Quantity
4. 1 x
5. 4 x
11. 1 x
13. 3 x
14. 1 x
15. 1 x
16. 1 x
17. 1 x
1 x
1 x
www.scheppach.com
Designation
Base frame
Castors
Vacuum hose
Suction pipe
Floor nozzle
Joint nozzle
Paper filter bag
Foam filter
Electric wet / dry vacuum cleaner
Operating manual
GB | 17
