Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.

Device description

Illustration A
Insertion for dust bag
1
Motor protection filter
2
Cover
3
Status display
4
Mains plug
5
Charging contacts
6
Suction opening
7
Dust bag
8

Functional description

The unit functions as a charging and suction station for
the RVC 3 Comfort cleaning robot.
As a charging station, the functionality is identical to the
charging station supplied with the cleaning robot.
In addition, the station is used for suction. Suction starts
when the cleaning robot has completed its cleaning
task. During the suction process, a flap in the dust con-
tainer of the cleaning robot is opened by the vacuum
created and the dirt is transported into the filter bag of
the station.
Suction can only take place under the following condi-
tions:
● The cleaning robot is in the station.
● A filter bag is suspended in the station.
● The inserted filter bag is not full.
● The station cover is closed.
Status displays
LED display Status
Flashes blue The cleaning robot is charging.
Lights up blue for 5 The cleaning robot is fully
seconds charged.
Lights up blue The cleaning robot is cleaning /
Suction is in process.
Malfunctions often have simple causes that you can
remedy yourself using the following overview. When in
Fault
Battery does not charge Charging contacts dirty.
8

Troubleshooting guide

Cause
Ambient temperature below 0 °C or
above 35 °C.
Station is not plugged in.
LED display
Lights up red
Off
Setting up the station
● Select the location so that the cleaning robot can
easily reach the charging station.
● Ensure a distance of at least 0.5 m to the left and
right of the charging station and a distance of at
least 1.5 m in front of the charging station.
● The location must not be exposed to direct sunlight.
1. Set up the charging station.
Illustration B
2. Connect the mains plug.
CAUTION
Risk of injury or damage due to the weight of the de-
vice!
Injury and damage.
Be aware of the weight of the device during transport
and storage.
CAUTION
Risk of injury or damage due to the weight of the de-
vice!
Injury and damage.
Be aware of the weight of the device during transport
and storage.
Care and service
Changing the dust bag
1. Open the cover.
2. Pull the full dust bag upwards to remove the bag.
3. If necessary, clean the interior and the motor protec-
tion filter of the station.
4. Unfold the new dust bag and push it into the support
from above.
5. Close the cover again.
6. Clean the filter of the dust container (see RVC 3 op-
erating instructions).
doubt, or in the case of malfunctions not mentioned
here, please contact your authorised Customer Service.
Rectification
1. Wipe the charging contacts on both the
charging station and the cleaning robot
with a dry cloth.
1. Use the cleaning robot at temperatures
above 0 °C and below 35 °C.
1. Plug in the power cable of the station.
English
Status
A fault has occurred.
The cleaning robot is charged
and in sleep mode or "Do not
disturb" mode.
Initial startup
Transport
Storage
