WPS 1000 R WPS 2000 R WPS 3000 R WPS 4000 R Gebrauchsanweisung TEICHPUMPE Operating Instructions POND PUMP...
Seite 2
EN 55014-2:1997 + A1:2001 + A2:2008 submersible pump EN 61000-3-2:2014 EN 61000-3-3:2013 WPS 1000 R EN 60335-1:2012 + A11:2014 WPS 2000 R EN 60335-2-41:2003 + A1:2004 + A2:2010 WPS 3000 R EN 62233:2008 WPS 4000 R EN 50581:2012 AfPS GS 2014:01 PAK Dokumentationsbevollmächtigter:...
Vor Inbetriebnahme bitte unbedingt die Gebrauchsanweisung lesen! Liebe Kundin, lieber Kunde, herzlichen Glückwunsch zum Kauf Ihres neuen Gerätes von T.I.P.! Wie alle unsere Erzeugnisse wurde auch dieses Produkt auf der Grundlage neuester technischer Erkenntnisse entwickelt. Herstellung und Montage des Gerätes erfolgten auf der Basis modernster Pumpentechnik und unter Verwendung zuverlässigster elektrischer bzw.
Erfahrung und Wissen benutzt werden, wenn sie beaufsichtigt oder bezüglich des sicheren Gebrauchs des Gerätes unterwiesen wurden und die daraus resultierenden Gefahren verstehen. Kinder dürfen nicht mit dem Gerät spielen. Reinigung und Benutzer-Wartung dürfen nicht von Kindern ohne Beaufsichtigung durchgeführt werden. Die Pumpe darf nicht benutzt werden, wenn sich Personen im Wasser aufhalten.
Menschen mit Herzschrittmacher sollten immer einen Sicherheitsabstand von mind. 30 cm zur Pumpe einhalten. 3. Technische Daten Modell WPS 1000 R WPS 2000 R Netzspannung / Frequenz 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz Nennleistung...
Alternativ können Sie auch den mitgelieferten Schlauchanschluss(14) direkt in den Pumpenausgang schrauben um z.B. einen Filter oder Bachlauf zu betreiben. Bei der WPS 1000 R und WPS 2000 R müssen vorher immer die mitgelieferten Reduzierstücke 1/2" AG auf 3/4" IG direkt auf die Pumpe montiert werden.
das Teichwasser gelangt. Spülen Sie alle gereinigten Teile sorgfältig mit sauberem Leitungswasser ab, bevor Sie die Pumpe wieder zusammensetzen und in Betrieb nehmen. Sollte die Pumpe stark verkalkt sein, können Sie die Laufeinheit und den Motorblock in Entkalkungslösung für Edelstahlteile einlegen. Bitte beachten Sie hierzu die Gebrauchsinformation des Entkalkers.
Darüber hinaus veröffentlichen wir dort umfassende Informationen und wertvolle Tipps zu unseren Produkten und Zubehör, stellen neue Geräte vor und präsentieren aktuelle Trends und Innovationen im Bereich Pumpentechnik. Ersatzteil Nr. Teile- WPS 1000 R WPS 2000 R WPS 3000 R WPS 4000 R Beschreibung 73244 73263...
Strictly ensure that you have read the use instructions before placing the pump in service! Dear Customer, Congratulations on your purchase of a new device from T.I.P.! As is the case with all of our products, this product has been developed on the basis of the latest technical expertise.
use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. The pump must not be used when people are in the water. The pump must be supplied through a residual current device (RCD) having a rated residual operating current not exceeding 30mA.
People with pacemakers should always maintain a safety distance of at least 30 cm from the pump. 3. Application areas Model WPS 1000 R WPS 2000 R Mains voltage / frequency 220 - 240 V~ 50 Hz 220 - 240 V~ 50 Hz Rated power...
Completely immerse the pump in your pond. Water will penetrate into the pump body. A water level of at least 20 cm is required for operation, so that the pump does not take in air. Only operate the pump at a maximum immersion depth ( ) of 2 m! ...
7.1. Maintenance intervals The time intervals for the required maintenance task (complete cleaning) to a great extent are based on the level of pond water contamination. Select the time intervals for cleaning accordingly. If, when performing maintenance tasks, you determine that there are defects or wear, replace the parts in question (see ordering spare parts).
9. Troubleshooting/recommendations Fault Possible cause Remedy No delivery capacity Power supply interrupted Plug in the power plug Check fuse Cable is defective Dispose of pump Motor block is defective Dispose of pump Pump is calcified, rotor has seized Dismantle pump and descale Rotor is blocked by sand Dismantle and clean pump Change the set up location as specified...
contained in the present operating instructions will therefore considerably contribute to a long lifecycle of these wearing parts. In case of complaints, we reserve the option of repairing or replacing the defective parts or replace the entire device. Replaced parts will pass into our property. Claims for liquidated damages are excluded unless they are caused by wilful acts or negligence on the side of the manufacturer.
Spare parts Part-No. WPS 1000 R WPS 2000 R WPS 3000 R WPS 4000 R Description 73244 73263 73299 73308 Pump Body 73245 73264 73300 73309 Rotor 73246 73265 73301 73310 Shaft/Impeller 73247 73266 73302 73311 Shaft/Sleeve 73248 73267 73303...
Seite 21
Slike Obrázky Dodatek: Slike WPS 1000 R – WPS 2000 R – WPS 3000 R – WPS 4000 R Abb. 3 WPS 1000 R / WPS 2000 R WPS 3000 R / WPS 4000 R WPS 2000 R / 3000 R / 4000 R...
Seite 24
T.I.P. Technische Industrie Produkte GmbH Siemensstraße 17 D – 74915 Waibstadt / Germany service@tip-pumpen.de www.tip-pumpen.de...
