• Rechargeable battery and charger with
instruction manual

Overview

The illustrations for the device
can be found on the front fold-
out page.
1 Drill chuck aperture
2 Keyless chuck
3 Torque adjustment ring
4 Gear selector switch
5 Magnet
6 Direction of rotation switch
7 Handle
8 Battery holder
9 LED work light
10 On/Off switch
11 Holder for auxiliary handle
12 Bits
13 Auxiliary handle (Insulated gripping sur-
face)
14 Charger
15 Battery
16 Button (Charge level indicator)
17 Charge level indicator
18 Battery release
19 Storage case
Fig. D
20 Belt clip

Description of functions

The 3-in-1 cordless impact drill screwdriver
with two-speed gearbox has 20 torque set-
tings, as well as one drill setting and one im-
pact setting, right/left rotation. The tool is
equipped with a keyless chuck and an LED
work light.
Please refer to the descriptions below for in-
formation on how the operating elements
work.

Technical data

Cordless Impact Driver .... PSBSA 20-Li C3
Rated voltage U ..................................20 V ⎓
No-load rotation speed n
– Level 1 .................................... 0–440 min
0
−1
– Level 2 .................................. 0–1650 min
Max. torque ......................................... 45 Nm
Impact rate ............................. 0-26400 min
Chuck capacity ............................ 1,5-13 mm
Weight with battery (20 V, 2 Ah) .........≈1.9 kg
Max. drilling diameter
–wood ................................................. 35 mm
–metal ................................................. 13 mm
–Concrete ........................................... 13 mm
max. screw diameter .......................... 10 mm
Protection type ....................................... IPX0
Temperature .......................................≤ 50 °C
– Charging .......................................4 – 40 °C
– Operation ................................. −20 – 50 °C
– Storage .........................................0 – 45 °C
Sound pressure level (L
–Idle .................................76.1 dB; K
–Impact drilling ................ 99.8 dB; K
Sound power level (L
–Idle ................................84.1 dB; K
–Impact drilling ............. 107.8 dB; K
Vibration (a )
h
–Drilling ....................... 2.71 m/s²; K=1.5 m/s²
–Impact drilling ......... 10.24 m/s²; K=1.5 m/s²
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1/
Smart PAPS 2012 A1
– frequency band ..............2400–2483.5 MHz
– transmitted power ....................... ≤ 20 dBm
Levels of noise and vibration were determ-
ined according to the standards and regula-
tions in the declaration of conformity.
The specified total vibration value and the
stated noise emission value have been
measured according to a standardised test
method and can be used to compare one
power tool with another. The specified total
vibration value and the stated specified noise
emission value can also be used for a provi-
sional assessment of the load.
WARNING! The vibration and noise emis-
sions may deviate from the specified values
during actual use of the power tool, depend-
ing on how the power tool is being used.
Try to keep the exposure to vibrations as
low as possible. An example of a measure
to reduce vibration exposure is limiting the
working hours. All parts of the operating
cycle have to be considered while doing so
GB MT
)
pA
=5 dB
pA
=5 dB
pA
)
WA
=5 dB
WA
=5 dB
WA
−1
−1
17
