NET-EXP
Index
1

Product Description

2

Technical Data

3
Electrical Connections
4
Status LED Description
5
NET-EXP Board Enablement
SYMBOLS
The following symbols are used within this manual to indicate potential hazards.
Important safety notice. Failure to follow these instructions may result in serious injury or damage to property. Failure to do so
may result in product malfunction and create a hazardous situation.
Important safety notice. Contact with live parts can result in death or serious injury.
Important information for installing, programming or commissioning the product.
1 PRODUCT DESCRIPTION
The "NET-EXP" and "NET-EXP mini" devices are accessories designed exclusively for pairing with the NET series control units.
NET-EXP allows you to manage up to 8 additional outputs, each of which has a normally closed (N.C.) and normally open (N.O.) output.
Additionally, there are 6 additional inputs available. Through the NET series control units, it is possible to customize the operation of each
input/output, ensuring maximum adaptability to any type of automation system.
NET-EXP mini is a more compact version that integrates directly onto the NET series control unit (only NET24N or NET230N). It offers
1 output and 4 additional inputs. In this case as well, it is possible to customize the operation of each input/output to meet the specific
needs of the system.
2 TECHNICAL DATA
For all outputs:
Contacts configuration
Rated voltage
NET-EXP mini
Rated current
NET-EXP 250 V ~ / 30 V
12-24 V ~ /
Max 2 A (only resistive loads)
Input/output expansion board for NET
series control units
User instructions and warnings
6 Input/Output Configuration
15
7 Input/Output Description
15
8
Detailed Parameter List
16
9
System Testing
19
10
Product Disposal
19
For all inputs:
Configurations to choose from:
- Free contact;
- 8K2 constant resistance.
NET-EXP
19
