5.3 Pre-assembly of 500/600 cm under frame
For the 500/600 cm version, hang the additional cross beam
2
underframe using the pre-assembled screws. Tighten both screws firmly.
Hook the other side of the cross beam into the suspension sockets of the remaining underframe
using the pre-assembled screws. Tighten the two screws firmly. Now turn the underframe over and
position it in the desired position.
1
into the suspension sockets of the
GB
2
3 5
