Connection to an external dust extraction system
(Fig. A)
m ATTENTION! An external dust extraction system
must not be connected when carrying out work that
generates sparks.
The dust extraction system must be suitable for the ma-
terial to be processed.
Use a special extraction device to extract dusts that are
particularly harmful to health or carcinogenic.
1. Push the suction adapter (9) onto the extraction
nozzle (10).
2. Connect a suitable dust extraction to the suction
adapter (9).
General working notes
• The work result and the surface quality are essen-
tially determined by the choice of brushing roller and
by the preselected speed.
• Work with the contact pressure as low as possible
in order to increase the service life of the brushing
roller. Excessively increasing the contact pressure
does not lead to a higher removal/cleaning rate, but
to greater wear of the device and the brushing roller.
• Work with moderate feed and carry out the working
process parallel and overlapping to the grinding path.
• Use only original accessories from the manufacturer.
• Only perfect brushing rollers provide good work re-
sults and protect the device.
• Make sure that the workpiece is always clamped and
secured in order to prevent ejection.
10. Transport
Always switch off the electrical tool before transport
and disconnect it from the power supply.
To transport the power tool, lift it by the centre struts.
Protect the electrical tool from impacts, shocks and se-
vere vibrations, e.g. during vehicular transport.
Secure the electric tool against toppling and slipping.
11. Maintenance and cleaning
m WARNING!
Pull out the mains plug before carrying out any setting,
servicing or repair work!
General maintenance tasks
• Always keep the cooling air openings in the housing
clean and clear for air circulation.
• Rub the device clean with a clean cloth or blow it off
with compressed air at low pressure.
• We recommend that you clean the device directly
after every use.
• Clean the device at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the device. Make sure that no water can
penetrate the device interior.
• There are no parts which can be repaired by the user
within the device. Never try to repair the device your-
self. Always contact a qualified specialist.
Replacing the connection cable
If the mains connection cable of the plunge saw is dam-
aged, it must be replaced by the manufacturer, their
service department or a similarly qualified person to
avoid dangers.
Service information
With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consumables.
Wearing parts*: Carbon brushes, brushing roller
* may not be included in the scope of delivery!
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.
12. Storage
Store the device and its accessories in a dark, dry and
frost-free place that is inaccessible to children. The
optimum storage temperature is between 5 and 30˚C.
Store the power tool in its original packaging.
Cover the power tool to protect it from dust or moisture.
Store the operating manual with the power tool.
13. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions. The custom-
er's mains connection as well as the extension ca-
ble used must also comply with these regulations.
Important information
In the event of overloading, the motor will switch itself off.
