Scheppach 5903822901 Originalbetriebsanleitung Seite 25

Special safety instructions for working with wire
brushes:
a. Note that the wire brush loses pieces of wire
even during normal use. Do not overtax the
wires by applying too much contact pressure.
Pieces of wire that fly off can easily penetrate thin
clothing and/or the skin.
b. If a protective cover is recommended, prevent
the protective cover and wire brushes from
touching. Disc and cup brushes can increase
their diameter due to contact pressure and cen-
trifugal forces.
Residual risks
The power tool is state-of-the-art and has been
built according to the recognised technical safety
regulations. However, individual residual risks can
arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Residual risks can be minimised if the "Important in-
formation" and the "Proper use" are observed along
with the whole of the operating instructions.
• Avoid accidental starting of the machine: the start
button may not be presse when inserting the plug
in a socket.
• Keep your hands away from the working area when
the machine is in operation.
• Before performing setting or maintenance work, re-
lease the start button and pull out the mains plug.
m WARNING
This power tool generates an electromagnetic field dur-
ing operation. This field can impair active or passive
medical implants under certain circumstances. In or-
der to prevent the risk of serious or deadly injuries, we
recommend that persons with medical implants consult
with their physician and the manufacturer of the medi-
cal implant prior to operating the power tool.
6. Technical data
Rated voltage
Rated input
Protection class
Idle speed n
o
Tool attachment Ø
230 - 240 V~ / 50 Hz
300 W
II
1600-3000 rpm
ø 60 mm
www.scheppach.com
Suction connection
Weight
Dimensions L x W x H
Subject to technical changes!
Noise/vibration information
m WARNING!
Working without hearing protection or protective cloth-
ing can result in damage to health.
• Wear hearing protection and appropriate protective
clothing when working.
Measured as per EN 62841-2-4 & EN 62841-1. The
noise at the work place can exceed 85 dB. In this case,
protective measures for the user are required (wear
suitable hearing protection).
Sound power level L
WA
Sound pressure level L
pA
Uncertainty K
wa/pA
The above mentioned values are device emissions
values and therefore do not necessarily represent safe
work place values. The correlation between emission
and exposure levels cannot reliably lead to a deriva-
tion of whether additional precautionary measures are
necessary or not.
Factors that could influence the respective emissions
level present at the work place include the specification
of the working area and the environment, the duration
of exposure, other noise sources and more.
Also pay attention to any possible deviations in the
national regulations for the reliable work place values.
However, the above mentioned information makes it
possible for the user to make a better assessment of
the dangers and risks.
Vibration emission value a
directions) and uncertainty
EN 62841-2-4 & EN 62841-1:
Vibration emission value (3-axle)
Typical weighted vibration a
Uncertainty K
approx. ø 27.5 mm
approx. 1.8 kg
410x 135 x 135 mm
94 dB
86 dB
3 dB
(vector sum, three
h
K determined per
= 7.31 m/s²
h
= 1.5 m/s²
GB | 25
