Fig. 8: Renaming series of measurements
If you would like to remove series of measurements from the software, you can highlight one or
more identifiers in the list of series of measurements and delete them by pressing the "Del" key on
your keyboard.
You can also do a right click and select "Delete".
Note:
Between the list of series of measurements on the left-hand side and the chart and statistics on the
right-hand side, there is a small area with a displacement line which is normally not visible. This line
can be used to change the allocation of the two areas, using your mouse.
To do so, place the cursor between the two areas until it changes. Then press and hold the left
mouse key. The vertical dividing line will become visible and can be moved left or right.
Export of series of measurements
A series of measurements can be exported. By clicking on the icon "Export measurement data" in
the toolbar, the complete content of the series of measurements can be exported in CSV format.
This export saves all measurement values line by line, along with some comment lines and the
seven attributes, separated by a semicolon ";".
These seven attributes are the same as the attributes shown in the chart (Fig. 5).
Loading and saving series of measurements
You can load and save a series of measurements by clicking on the "Load a series of measurements
from a file" or "Save a series of measurements in a file" icon on the toolbar.
When you want to save a series of measurements, the typical Windows dialogue for saving data will
appear first. This dialogue can be used to select a folder and a create a file name.
The file format cannot be changed.
