3.2

Connections and sensors

01 Probe connection
02 Temperature sensor
03 Connection for Mini USB cable
04 Connection for mains cable
3.3

Function keys

Key
"MEAS"
"SAVE"
"CAL"
"MENU"
"OK"
"DEL/UNIT"
"a "
0
" "
" "
"▲"
"▼"
Function
Measurement
Storage of measurement data
Calibration
Function set-up / settings
Confirmation
DEL: Deletion (in viewing mode)
UNIT: Change of unit (in measurement mode)
Selection of temperature coefficient
Backlight
On / off
Increasing in steps or moving upwards
Decreasing in steps or moving downwards
