Connect with the "PCE-COM 20"
After making the desired settings and closing the settings dialogue by clicking on the "Apply" button,
you can establish a connection to the "PCE-COM 20" by clicking on the corresponding icon
("Connect with the "PCE-COM 20"").
If the connection was established successfully, the word "Connected" in the status bar for the
dynamic data will be displayed in green.
If no connection was established, the word "Disconnected" will be shown in red.
Possible scenarios
The connection to the "PCE-COM 20" was established successfully.
There is no connection to the selected COM port.
Disconnect from the "PCE-COM 20"
You can click on the corresponding icon ("Disconnect from the "PCE-COM 20"") to disconnect
an active connection to the "PCE-COM 20".
Closing the software while the connection is active will also terminate the connection.
The connection to the "PCE-COM 20" was terminated.
