The LED work light
is intended to illuminate the immediate
work area.
Any other use or modification of the
product are considered improper use
and can result in hazards such as
death, life-threatening injuries and
damage. The manufacturer is not liable
for any damages caused by improper
use. The product is not intended for
commercial use or for any other use.
˜ Scope of delivery
WARNING!
m
The product and the packaging are
u
not children's toys! Children must
not play with plastic bags, sheets
and small parts! There is a danger of
choking and suffocation
1 20V Cordless drill driver
1 Belt clip (Pre-assemble)
1 Carrying case
1 User manual
˜ Parts description
Before reading, unfold the pages
containing the illustrations and familiarise
yourself with all functions of the product.
Figure A:
Chuck
[ 1 ]
Chuck ring
[ 2 ]
Torque sleeve
[ 3 ]
Gear selector
[ 4 ]
Bit holder (magnetic)
5 ] [
Rotation direction switch/lock
6 ] [
On/off switch/speed control
7 ] [
Grip handle
[ 8 ]
Belt clip (Pre-assemble)
[ 9 ]
button charging level
[ ]
Charging level LEDs (red/orange/green)
[ ]
Battery pack *
[ ]
Release button for battery pack
[ ]
LED work light
[ ]
* Battery pack and charger are not included.
on this product
[ ]
Figure B:
Charger *
[ ]
Charging control LED – Red
[ ]
Charging control LED – Green
[ ]
Not illustrated:
Carrying case
[ ]
˜ Technical data
20V Cordless drill
driver
Rated voltage:
Drill chuck type:
Gearbox:
No-load speed n :
0
1 gear:
st
2 gear:
nd
Max. torque:
Chuck clamping
range:
Max. drill diameter: into steel Ø 13 mm
Battery pack
Model number:
Type:
Rated voltage:
Capacity:
Energy value:
Number of cells:
Temperature:
Charger
Model number:
Input:
Rated voltage:
Rated frequency:
PABS 20-Li I9
20 V
keyless chuck
2 speed
0–430 min
–1
0–1 00 min
–1
45 N m
max. Ø 13 mm
into wood Ø 30 mm
PAP 20 B
HG08297
Lithium-Ion
20 V max.
2.0 Ah
40 Wh
5
max. +50 °C
PLG 20 C
HG08982
VDE plug
HG08982-BS
UK plug
230–240 V~
50 Hz
GB/IE 27
